HPC Self-Regulating Heating Cable
HPC Self-Regulating Heating Cable
HPC Self-Regulating Heating Cable
HPC Self-Regulating Heating Cable
HPC Self-Regulating Heating Cable
HPC Self-Regulating Heating Cable
HPC Self-Regulating Heating Cable
HPC Self-Regulating Heating Cable

HPC Self-Regulating Heating Cable

Max. Exp. Temp.: 260°C

Max. Maint. Temp.: 210°C

The HPC self-regulating heating cable is a high-end model developed by Huanrui specifically for ultra-high-temperature industrial working conditions. It features a maximum maintenance temperature of 210°C and a maximum exposure temperature of 260°C. Constructed with a special high-temperature PTC core and an all-fluoropolymer structure, it delivers exceptional high-temperature stability, minimal heat attenuation, and a long service life. Engineered for harsh high-temperature, heavy-load, and highly corrosive environments, it is the ideal choice for industrial ultra-high-temperature heat tracing applications.

Inquiry
  • Overview
  • Recommended Products

Application

Widely used for freeze protection and temperature maintenance on 210°C-grade process pipelines, storage tanks, valves, flanges, and special equipment. It is especially suitable for high-power, highly corrosive, and high-temperature combined working conditions. Common applications include oil refining, chemical, fine chemical, oil and gas transportation, steam tracing, high-temperature storage tanks, pressure vessels, kiln surroundings, heat treatment equipment, and hazardous area heating projects.



Feature

  • Ultra-High Temperature Resistance: Maintains up to 210°C continuously and withstands 260°C short-term, meeting extreme process requirements.
  • Wide High-Power Range: Available in 15–90 W/m options, ideal for heavy-duty, long-distance heat tracing.
  • Ultra-Low Attenuation: Special high-temperature PTC formulation ensures stable power output and long service life under prolonged high temperatures.
  • All-Fluoropolymer Protection: Fluoropolymer outer jacket resists acids, alkalis, solvents, oil, and steam corrosion.
  • Safe & Reliable: Complete explosion-proof certifications for use in both hazardous and ordinary areas.
  • Flexible Installation: Cuttable to any length, safe to overlap; installable at temperatures as low as -60°C.



Technical Data

Outer Jacket: Fluoropolymer

Output wattage: 15,30,45,60,75,90 (W/m)

Max. resistance of braid: ≤18.2Ω/km

Bus Wire Gauge: 1.21mm² & 1.37mm²

Rated voltage: 110-120V,220-240V

Maximum maintain temperature: 210°C

Maximum exposure temperature: 260°C

Min. Installation Temperature: -60°C



HPC Series

Output
power
@+10℃
(W/m)

Maximum
maintain
temperature
(℃)

Max length
@+10℃
16/32/50A
(m)

Max length
@+0℃
16/32/50A
(m)

Max length
@-20℃
16/32/50A
(m)

Dimension
(mm)

Weight
(kg/100m)

15HPC2-SF

15

210

120/169/169

118/169/169

98/169/169

10.8×5.0

12.5

30HPC2-SF

30

210

81/118/188

75/118/118

65/118/118

10.8×5.0

12.5

45HPC2-SF

45

210

61/100/100

57/100/100

48/98/100

10.8×5.0

12.5

60HPC2-SF

60

210

48/87/87

43/87/87

30/82/87

10.8×5.0

12.5

75HPC2-SF

75

210

32/71/75

24/54/75

17/39/60

10.8×5.0

12.5

90HPC2-SF

90

210

20/40/62

16/30/48

10/22/34

10.8×5.0

12.5
