TECHNICAL DATA |
MSR SERIES |
|
Power output |
MSR-P |
|
Maximum maintain temperature |
MSR-PB |
|
Maximum exposure temperature |
MSR-PF |
|
Minimum installation temperature -60°C |
Max resistance of braid |
|
Rated voltage |
Bus wire gauge |
INTRODUCTION
MSR self-regulating heating cables provide the most versatility in heat trace designs and applications. Constructed of a semi-con- ductive heater matrix extruded between parallel bus wires, a self-regulating cable adjusts its output to independently respond to ambient temperatures all along its length. As temperature increases, the heater’ s resistance increases, which lowers the output wattage. Conversely, as the temperature decreases, the resistance decreases and the cable produces more heat. So thermostat is not necessary in some applications. It will never overheat or burnout even when overlapped. The cable can also be cut to any length. As the result, we got an energy efficient heating cable.
APPLICATION
MSR is ideally used for process temperature maintenance and frost protection of small diameter pipelines, tanks, valves, flanges. It is suitable for non-hazardous area, and cable with fluoropolymer outer jacket can also be used in hazardous area and corrosive area. What's more, the MSR with fluoropolymer out jacket can be used inside the water pipe heating. The material has safety cer- tificate for drinking water . It's safe and made to comply with the environmental protection standards.
